In the java.util package there is a class named Observable. It's been there a while, let's dust it off and use it to make our Restaurant Simulator hummmm.
Learn more
- Observable Java docs
- This is the other Observable from Reactive Extensions
Related Discussions
Have questions about this video? Start a discussion with the community and Treehouse staff.
Sign upRelated Discussions
Have questions about this video? Start a discussion with the community and Treehouse staff.
Sign up
So in order to make all the different
configuration changes to our restaurant
0:00
simulator throughout our day,
0:03
it's clear that we're going to need
to make things more extensible.
0:05
Different clients are gonna
have different needs, and
0:09
we need to be able to configure things for
each of our clients specifically.
0:11
Observer to the rescue.
0:15
So I've got some great news for you.
0:16
The Observer pattern has been included in
the JDK pretty much from the beginning.
0:18
It's fairly well documented, and
it's pretty straightforward to implement.
0:23
There are some complaints about
the way that it's implemented,
0:26
and we'll explore those after we get
our hands dirty with it a little bit.
0:29
Now, a quick word of warning here.
0:32
There's been a somewhat recent trend in
what is known as reactive extensions.
0:34
RxJava is the Java flavored version.
0:38
Reactive extensions make use of
the Observer pattern combined
0:41
with the the Iterator pattern to deal
with strands of data and events.
0:44
It's everywhere these days.
0:47
But I wanted to warn you that there's
a bit of a namespace collision
0:49
around a term that we
are about ready to use.
0:52
That term is observable.
0:55
The observable from
the reactive extensions world
0:57
is different than what we're
going to be exploring.
1:00
Check out the teacher's notes for more and
1:02
just know that they
are two different things.
1:04
Ready?
1:07
Let's dive in.
1:07
All right, so in java.util there
is a class named Observable, and
1:10
this is what we're going to
use to mark our subjects.
1:15
So in our case, the staff and
1:17
the dashboard are observing
changes to the table.
1:19
So the table is the subject.
1:22
So let's go ahead and
let's pop open the table.
1:25
And what we'll do is we'll have
it extend that Observable class.
1:29
So we'll say extends Observable.
1:32
Now we have all of the methods
available to us from Observable.
1:37
Now, basically, we have now exposed
the ability to have Observer subscribe and
1:40
have added the ability to
notify them when things change.
1:46
While we're in here, why don't we set up
what it is that we want to broadcast?
1:49
So we're interested when
the status changes, right.
1:54
So let's go to that status setter here.
1:57
We'll come in here, so
status newStatus, and
2:00
what we'll do is we'll
notify the observers.
2:04
So let's say notify, and see,
it's now part of this, Observers.
2:08
Now this notifyObservers takes an optional
argument, which can be anything at all.
2:12
Now, the parameter is used
to narrow the focus of
2:17
what it was specifically that was changed.
2:20
So in our case, it probably makes sense
for us to push the status through.
2:23
You don't have to do this.
2:27
This is a totally fine call.
2:28
Let's do it anyway, though.
2:29
So let's say, we'll pass through
the new status that got set.
2:30
Now, there is one thing that we
need to remember to do when we're
2:34
using the Observable class.
2:37
And pay close attention here,
because this will for sure bite you.
2:39
So the way that notifyObservers
works is it will
2:42
only send out notifications only if
it's been told that changes were made.
2:46
Now, this allows you to make sure that
you can control when your observers
2:52
are notified.
2:56
You must call setChanged, and you need to
do it before the notifyObservers happens.
2:57
So it's called setChanged.
3:04
So what that does is that it lets
it know that things changed.
3:06
So after the notification happens,
the state will turn back to unchanged.
3:09
So you can also check that by
using a method called hasChanged.
3:15
Now, I'm not gonna add
any protection here,
3:19
as I want any tweak in our
status to trigger events, right?
3:21
So what do you say we look at how to
create an observer to observe changes to
3:24
our table.
3:29
Okay, so let's go ahead and
we'll tackle this first issue here, right?
3:30
The staff will not like needing to
refresh the desk dashboard, right.
3:33
So let's do that.
Let's go over to the dashboard.
3:37
So let's open it up,
we'll go Shift Shift dashboard.
3:39
And what we'll do is we'll
have the Dashboard implement
3:42
the Observer interface, also in java.util.
3:47
Now, immediately, we'll see a squiggly,
3:51
because the interface has a required
method, which if we go ahead and
3:54
try to see what it's angry about,
it'll ask us to implement it.
3:59
So implement methods.
4:04
And it's one named update, and
it takes an Observable and an Object.
4:06
So this is a method that is called from
within that notifyObservers method
4:14
on the other side, right.
4:19
So as you can see, it's passed
an Observable, which it's called o here.
4:20
And the second parameter arg is an object.
4:26
So in our case that would be the status
object that we passed across, or
4:29
it's null in most cases.
4:32
So the idea here is, in this update
method, it's where you add the code that
4:34
will respond to the change in the class
that this will eventually observe.
4:39
That make sense?
4:43
So what do we want the dashboard to
do when a specific table changes?
4:44
Well, ideally and
4:49
probably realistically, we'd update
that single table in the dashboard.
4:50
But we don't have a way
to do that right now.
4:55
So let's just go ahead and
call the render method, right?
4:57
So if I put in here, say, render.
5:00
Now any time a table changes,
the dashboard will update automatically.
5:03
Well, that is, of course,
if we're observing it.
5:08
So let's go take a look at our simulator,
5:11
the main method here, and
take a look at what's happening.
5:14
First of all, we can get rid of
this refreshDashboard, right?
5:18
Before, the server was having to do it,
and the assistant was having to do it.
5:21
So we'll remove this.
5:26
There's no more dashboard refresh.
5:28
It looks like most of this is actually
gonna start going away here pretty
5:30
soon, right?
5:33
Really what we want,
is we want for each table,
5:35
we'll make the dashboard observe it.
5:38
And there's a method that was added by the
Observable superclass named addObserver.
5:40
Our tables have that.
5:45
So let's go ahead and let's,
right after we go here,
5:47
let's do tables.forEach,
5:52
for each table, we'll add
5:57
the observer of dashboard.
6:01
There we go.
6:08
Now the dashboard is watching all the
tables, and when the table state changes,
6:09
it will notify all of its observers and
the dashboard will render.
6:14
Nice.
So
6:21
I'm pretty sure we can
remove this concern, right?
6:21
The staff will not liking
needing to refresh it, so
6:24
we'll automatically refresh now.
6:26
Awesome.
6:27
Okay, let's see if we can't
take care of this next one.
6:29
The servers should be assigned to a table.
6:31
Well, now that we know about addObserver,
6:34
it seems like we just need to have
them observe specific tables, right?
6:36
You know what, let's do that for server.
6:41
Let's go ahead and
let's come over here to the simulator,
6:43
and let's cut this logic for the server
out of the main loop here, right.
6:49
So we're gonna grab, these two cases
are both server-based, right, so,
6:54
they're gonna not be in here,
server-based solution there.
7:00
Okay, and now let's open up server.
7:05
So I'm just gonna do Shift Shift server.
7:07
And we'll make this server
implement the observer.
7:12
Now, wait a second, all employees
should be able to observe a table.
7:16
So let's do that, let's make the employee
actually implement the observer.
7:21
So we'll say implements Observer.
7:26
And you'll notice that we
don't get a squiggly, and
7:30
that's because it's abstract.
7:33
So it's not required to be there yet.
7:35
But if we come back to our server,
7:37
now our server needs to have
the observer method there.
7:38
So let's go ahead and implement
the methods, and we'll do the update.
7:42
And I have in my clipboard,
I pasted that original.
7:48
I pasted it at the wrong place.
7:58
There we go, so we'll paste.
8:01
All right.
8:03
So we will do,
first I'm gonna clean up this little bit.
8:05
Get rid of all of this
optional stuff here.
8:15
So if it's available,
we'll do a leadToTable and we'll break.
8:17
And if it's finished,
we'll just close out the table.
8:24
And it's complaining about not
knowing what the table is.
8:29
So we need to define that, don't we?
8:32
We also need to define
the switch bit here.
8:35
So we definitely need to access the table,
right?
8:38
So what can we do?
8:41
So we can say table, and remember, it's
passed in through that observable there.
8:42
But it is an observable, so
we need to do a downcast to the table.
8:47
Yuck, right?
8:53
And now let's go ahead and add that
switch statement, now that we have that.
8:56
So we'll say switch, and
we'll do table.getStatus.
9:00
And in here, we'll add our case
statements that we had from before.
9:07
Tab that in once there.
9:13
There, that's looking a lot better.
9:15
Okay, so if the table's available,
we'll view the table,
9:18
otherwise we'll finish on that.
9:20
Cool.
9:23
Okay, and now, we know how to assign these
tables, right, we just assign them, right?
9:25
So we add observers to those tables.
9:29
So let's come in, and why don't we
move our observer stuff down below.
9:31
So let's move all the stuff where we
started doing the observers down here.
9:38
And so let's just for
each table, we'll say,
9:42
table1.addObserver, and
we'll have Alice watch the first three.
9:46
That sound good?
9:52
So we'll say, Alice, 2, 3.
9:53
And then let's for 4 and 5,
let's have Bob watch those.
9:57
So Alice and Bob all both servers.
10:02
So Bob's got 4 and 5, and
Alice only has 1 and 2.
10:05
So now they shouldn't pick up
each other's checks, right?
10:09
That's what the client
was concerned about here.
10:13
So let's flip over,
server should be assigned to a table, bam.
10:17
All right, so
why don't we take a quick break,
10:23
this has been going on for a little bit.
10:25
And we'll return and fix up the assistant
to use the pattern as well.
10:26
You know, why don't you try to
then tackle the assistant, right?
10:31
Try to make that assistant observable.
10:34
And then tune back in and
check out how I did it.
10:36
You got this.
10:38
You need to sign up for Treehouse in order to download course files.
Sign upYou need to sign up for Treehouse in order to set up Workspace
Sign up
